| Tonnage | 60 | ||
| Application | Compression Molding | ||
| Industry | Consumer Goods | ||
| Frame Style | 4-Post | ||
| Special Features | • 2 dual shuttle systems for upper & lower cavity • Water heated platens | ||
| Intended Use | Used to in a compression molding application to form recycled rubber into landscape edging for the consumer goods industry |
Custom Features:
- (4) 5” diameter chrome housing posts with graphite impregnated bronze bushings for superior ram guidance and rigidity
- (2) 64” x 160” dual shuttles on each press facilitate continuous part loading & forming
- (4) 64” x 80” working areas (two per cavity) with (2) side actuators to perform a pin assembly application
- Platens heated up to 150-deg. F. by a closed-loop water system
- Quick-die change hydraulic clamps on both cavities for tool mounting
- Bolt on expanded metal guards with safety interlocks cover the side openings
- Skid mounted power system and reservoir
- Kidney loop filter/cooler circuit with thermostatically-controlled electric fan-powered oil cooler
- Calculated Ram Speeds: Pressing 179 IPM; Return 322 IPM
